Description
Find the updated product here:
New and complete LED display (blue) ultra-bright for Bally / Stern / Bell Games pinball machines
(kit version to solder)
The display is the answer to the pinball lovers who were looking for new colors and technology for their Bally/Stern 6 or 7 digits pinball machines.
(Bally AS-2518-15 / Bally AS-2518-21 / Bally AS-2518-58 / Stern A-434 / Stern DA-100 / Stern DA-300 / Stern A-472 /Â Stern A-645 / …)
The complete pinball list is published at the end of this AD.
This new and complete LED display replaces the old gas display and operates with 5 volts voltage already present in the pinball machine.
You don’t have to replace all the displays since you can use both led and original displays at the same time.
IMPORTANT
You don’t have to modify anything inside the pinball, the display is plug & play and can be installed on any Bally/Stern/Bell Games pinball which uses these models.
The new LED display has a brightness regulator in order to adapt the LEDs brightness to the old displays.
It is provided with angle brackets for a better rigidity of the LED module and a “light shield foam” in order to insulate the digits from the lamp light.
A jumper present on the board will give you the option to enable or disable the decimal dot.
It is not necessary to be an expert do assemble the display, just a good soldering machine and some passion.
A complete and detailed assembly guide is provided with the kit.
Do you want more colors?
Just associate the white led digits with a color gel filter and you’ll be able to generate as many colors as you want!
Color gel filters are not provided with the display but are easy to find on Internet.
Let’s have a resume of the advantages of this display:
– No more High Voltage
– Very low current usage, no worries for your 5v power regulator
– One display is compatible with all similar pinball machines using 6 or 7 digits
– You can easy enable or disable the dot for decimals
– Led displays are modular, you can swap the 6 digits module with a 7 digits module
– Easy to assemble, very basic soldering knowledge is enough to do the job
– Better stability with the angle bracket provided with
– Plug&Play – no modifications needed on your old pinball machine
– Brightness regulator (Now can be installed on rear or front of the display board)
– Designed in Europe
– 2 years warranty
– Light shield foams
List of pinball machines (could contain mistakes)
Bally / Stern games (1977-1984)
Game | Number of 6-Digit: | Number of 7-Digit: |
AS-2518-15 AS-2518-21 |
AS-2518-58 | |
Bally 1977-1984 | ||
BLACK JACK | 5 | |
BLACK PYRAMID | 1 | 4 |
BMX | 1 | 4 |
CENTAUR I & II | 1 | 4 |
CYBERNAUT | 1 | 4 |
DOLLY PARTON | 5 | |
EIGHT BALL | 5 | |
EIGHT BALL DLX. | 1 | 4 |
ELEKTRA | 2 | 4 |
EMBRYON | 5 | |
EVEL KNIEVEL | 5 | |
FATHOM | 1 | 4 |
FIREBALL CLASSIC | 1 | 4 |
FIREBALL II | 1 | 4 |
FLASH GORDON | 1 | 4 |
FREEDOM | 5 | |
FRONTIER | 1 | 4 |
FUTURE SPA | 5 | |
GOLD BALL | 5 | |
GRAND SLAM | 4 | |
HARLEM G.T. | 5 | |
HOTDOGGIN’ | 5 | |
KISS | 5 | |
KINGS OF STEEL | 1 | 4 |
LOST WORLD | 5 | |
MATA HARI | 5 | |
MEDUSA | 2 | 4 |
MR & MRS PAC MAN | 2 | 4 |
MYSTIC | 5 | |
NIGHT RIDER | 5 | |
NITRO GROUNDSHAKER | 5 | |
PARAGON | 5 | |
PLAYBOY | 5 | |
POWER PLAY | 5 | |
RAPID FIRE | 1 | 2 |
ROLLING STONES | 5 | |
SILVERBALL MANIA | 5 | |
SIX MILLION $ MAN | 7 | |
SKATEBALL | 1 | 4 |
SPACE INVADERS | 5 | |
SPEAKEASY | 1 | 2 or 4 |
SPECTRUM | 1 | 4 |
SPY HUNTER | 1 | 4 |
STAR TREK | 5 | |
STRIKES & SPARES | 5 | |
SUPERSONIC | 5 | |
VECTOR | 2 | 4 |
VIKING | 5 | |
VOLTAN | 5 | |
X’s & O’s | 1 | 4 |
XENON | 1 | 4 |
Game | Number of 6-Digit: | Number of 7-Digit: |
DA-100 A-434 |
DA-300 A-645 |
|
Stern 1977-1981 | ||
ALI | 5 | |
BIG GAME | 1 | 4 |
CATACOMB | 1 | 4 |
CHEETAH | 1 | 4 |
COSMIC PRINCESS | 5 | |
DRACULA | 5 | |
DRAGONFIST | 1 | 4 |
FLIGHT 2000 | 1 | 4 |
FREEFALL | 1 | 4 |
GALAXY | 5 | |
HOT HAND | 5 | |
IRON MAIDEN | 1 | 4 |
LAZER LORD | 5 | |
LECTRONAMO | 5 | |
LIGHTNING | 2 | 4 |
MAGIC | 5 | |
MEMORY LANE | 5 | |
METEOR | 5 | |
NINE BALL | 1 | 4 |
NUGENT | 5 | |
ORBITOR 1 | 5 | |
PINBALL | 5 | |
QUICKSILVER | 1 | 4 |
SEAWITCH | 1 | 4 |
SPLIT SECOND | 1 | 4 |
STAR GAZER | 1 | 4 |
STARS | 5 | |
STINGRAY | 5 | |
TRIDENT | 5 | |
VIPER | 1 | 4 |
WILD FYRE | 5 |
Bell Games 1980-1985 | ||
ALL GAMES | 5x6Digits |
